OWL LIFTER INSTALLATION
OWL LIFTER GALLERY
STEP 1: Turn the Onewheel upside down and remove the two screws (4 total) at the furthest point of the front and back. These screws mount the bumper to the front and back foot pad.
STEP 2: If a spacer was provided (based on board type), align the spacer to the Lifter, and check to ensure the screw holes are aligned.
STEP 3: Insert two mounting bolts into the holes from the Titanium side through the spacer and tighten the bolts by hand.
STEP 4: Finish tightening the bolts with Allen wrench.
STEP 5: Install Slip Grip by sliding the pad over the top flange of the Lifter with the smooth surface on the top.
STEP 6: Apply grip tape horizontally to the vertical wall of the inside of the unit between your footpad and the Slip Grip.
